Sikaplan® WP Disc

Sikaplan® WP Disc

Fixing disc for PVC membranes

Sikaplan® WP Disc is a ready-to-use fixing disc based on polyvinylchloride (PVC-p).

  • Predefined breaking point to avoid membrane overstress
  • High flexibility for easy fixation at low temperatures
  • Fast fixation with nailing gun system in shotcrete
  • All membranes based on PVC-p can be heat welded onto this disc
  • Can be installed on wet substrates
Product Data Sheet Show all documents

Usage

The Product is used for:
  • Temporary fixing of geotextiles and drainage layers under sheet membranes
  • Temporary fixing of PVC-p sheet membranes


Advantages

  • Predefined breaking point to avoid membrane overstress
  • High flexibility for easy fixation at low temperatures
  • Fast fixation with nailing gun system in shotcrete
  • All membranes based on PVC-p can be heat welded onto this disc
  • Can be installed on wet substrates

Packaging

Products packed in boxes.

Refer to the current price list for available packaging variations.

Colour

Appearance

Round shape with a smooth surface on top and a centre hole for nails with washer.

Colour

black

Product Details

Product Information

Composition / Manufacturing

PVC-p

Shelf Life

5 years from date of production

Storage Conditions

The Product must be stored in original undamaged packaging in cool and dry conditions. It must be protected from direct sunlight, rain, snow and ice. Always refer to packaging.

Diameter

~80 mm

Thickness

~10 mm

Unit weight

~30 g
System information

System Structure

ANCILLARY FIXING TOOLS (SUPPLIED BY OTHERS):

  • Nailing system (such as Hilti DX 36): nailing gun including cartridges, compatible nails and washer for fixings into shotcrete

  • Steel spikes with steel washers (such as Hasko rivets) to be driven by hammering into pre-drilled holes in reinforced concrete

Technical Information

Resistance to UV Exposure

Not permanently UV stable

Resistance to Weathering

Not resistant to permanent weathering



Application

Application steps

APPLICATION INSTRUCTIONS

IMPORTANT

Strictly follow installation procedures

Strictly follow installation procedures as defined in Method Statements, application manuals and working instructions which must always be adjusted to the actual site conditions.

APPLICATION

IMPORTANT

Application by trained personnel

The application of this Product must only be carried out by an applicator that is trained or approved by Sika. The applicator must also be experienced in this type of application.

For information on application, refer to the following:

  • Sikaplan® WP sheet membrane (PVC) system for waterproofing basements and other below ground structures

  • Sikaplan® WP sheet membrane (PVC) system for waterproofing tunnels



SUBSTRATE QUALITY

For information on substrate quality and pre-treatment, refer to the following Sika® method statements:

  • Sikaplan® WP sheet membrane (PVC) system for waterproofing basements and other below ground structures

  • Sikaplan® WP sheet membrane (PVC) system for waterproofing tunnels
