Sikalastic®-532 Pronto
TWO-COMPONENT ELASTOMERIC PUMA BINDER FOR TRAFFIC DECK APPLICATIONS
Sikalastic®-532 Pronto is a fast curing, elastomeric self-levelling binder based on polyurethane-modified reactive acrylic resins (PUMA), as part of the Sikalastic® Pronto RB-5700 PUMA system.
- Low temperature crack bridging (1.6 and 3.2 mm) per ASTM C1305/C957 (-26 °C / -14.8 °F)
- Very fast curing, even at low temperatures
- High elongation at break, even at low temperatures
- Good mechanical and chemical resistance
- Elastomeric
- Solvent-free
Usage
Sikalastic®-532 Pronto functions as both a neat crack-bridging basecoat membrane and as a flexible binder in the wear course of the Sikalastic® Pronto RB-5700 PUMA system for multi-storey and underground carparks, intermediate and exposed decks.Advantages
- Low temperature crack bridging (1.6 and 3.2 mm) per ASTM C1305/C957 (-26 °C / -14.8 °F)
- Very fast curing, even at low temperatures
- High elongation at break, even at low temperatures
- Good mechanical and chemical resistance
- Elastomeric
- Solvent-free
Packaging
Part A: Sikalastic®-532 Pronto | 18.9 L (5 US gal.) pail |
Part B: Sikafloor® Pronto Hardener | 25 kg (55 lb) bag (sold separately, see Mixing Ratio chart below for dosage) |
Sikalastic®-1 Pronto Filler | 18 kg (39 lb) bag |
Colour
Part A: Sikalastic®-532 Pronto | Liquid / Gray |
Part B: Sikafloor® Pronto Hardener | Powder / White |
Sikalastic®-1 Pronto Filler | Fine aggregates / White |
Product Details
APPROVALS / CERTIFICATES
- Passes low temperature crack bridging (1.6 and 3.2 mm) per ASTM C1305/C957 (-26 °C)
- Crack-bridging test EN 1062-7
- Fire testing EN 13501-1
Composition / Manufacturing
PU-modified poly-methyl-methacrylate based resin
Shelf Life
From date of production:
Part A: Sikalastic®-532 Pronto | 12 months |
Part B: Sikafloor® Pronto Hardener | 12 months |
Sikalastic®-1 Pronto Filler | Unlimited |
Storage Conditions
Sikalastic®-532 Pronto and Sikafloor® Pronto Hardener: Stored properly in original, unopened and undamaged sealed packaging, in dry conditions at temperatures between 5 and 30 °C (41 and 86 °F). Materials must be protected from heat, direct sunlight, moisture and impact. The materials should be stored between 18 to 24 °C (65 to 75 °F) for 24 hours prior to use for optimum handling properties. Do not store near open flame or an ignition source.
Density
~ 0.99 kg/L (23 °C / 73 °F)
Solid content by weight
~ 100 %
Solid content by volume
~ 100 %
Crack Bridging Ability
Passes ASTM C1305 for both 1.6 and 3.2 mm crack width (in accordance with ASTM C957) |
Pull-Off Strength
> 1.5 MPa (failure in concrete)
Temperature Resistance
Exposure* | Dry Heat |
Permanent | 40 °C (104 °F) |
Short-term max. 2 days | 50 °C (122 °F) |
Short-term max. 1 hour | 60 °C (140 °F) |
Short-term heat* up to 80 °C (176 °F) where exposure is only occasional (steam cleaning etc.)
*No simultaneous chemical and mechanical exposure and only in combination with Sikalastic®-511 / -518 Pronto as a broadcast system with approx. 3 - 4 mm thickness.
Application
Mixing Ratio
Amount of Sikafloor® Pronto Hardener required to be added to 9.5 L (2.50 US gal.) or 9.36 kg (20.63 lb) of Sikalastic®-532 Pronto is dependent on the ambient and substrate temperature.
Temperature | Hardener | (% part by weight) |
0 °C (32 °F) | 561 g (19.7 oz) | 6.0 % |
5 °C (41 °F) | 561 g (19.7 oz) | 6.0 % |
10 °C (50 °F) | 374 g (13.1 oz) | 4.0 % |
15 °C (59 °F) | 281 g (9.9 oz) | 3.0 % |
20 °C (68 °F) | 187 g (6.5 oz) | 2.0 % |
25 °C (77 °F) | 141 g (5.0 oz) | 1.5 % |
30 °C (86 °F) | 94 g (3.3 oz) | 1.0 % |
Note: The hardener powder can also be ordered under the product name Sikadur® VPC Part B (280 g / 9.87 oz bottle)
Ambient Air Temperature
0 °C (32 °F) min. / 30 °C (86 °F) max.
Relative Air Humidity
~ 80 % R.H. max.
Dew Point
Beware of condensation! The substrate and uncured floor must be at least 3 °C (5 °F) above dew point to reduce the risk of condensation or blooming on the floor finish.
Substrate Temperature
0 °C (32 °F) min. / 30 °C (86 °F) max
Substrate Moisture Content
≤4 % pbw moisture content. Test method: Tramex meter.
Pot Life
Temerature | Time |
0 °C (32 °F) | ~ 20 minutes |
5 °C (41 °F) | ~ 20 minutes |
10 °C (50 °F) | ~ 15 minutes |
15 °C (59 °F) | ~ 15 minutes |
20 °C (68 °F) | ~ 15 minutes |
25 °C (77 °F) | ~ 12 minutes |
30 °C (86 °F) | ~ 10 minutes |
Times are approximate and will be affected by changing ambient conditions particularly temperature and relative humidity.
Curing Time
Before overcoating Sikalastic®-532 Pronto allow:
Temperature | Time |
0 °C (32 °F) | ~ 80 minutes |
5 °C (41 °F) | ~ 80 minutes |
10 °C (50 °F) | ~ 60 minutes |
15 °C (59 °F) | ~ 50 minutes |
20 °C (68 °F) | ~ 45 minutes |
25 °C (77 °F) | ~ 35 minutes |
30 °C (86 °F) | ~ 10 minutes |
Times are approximate and will be affected by changing ambient conditions particularly temperature and relative humidity.
Applied Product Ready for Use
Temperature | Foot Traffic | Full Cure |
0 °C (32 °F) | ~ 80 minutes | ~3 hours |
5 °C (41 °F) | ~ 80 minutes | ~3 hours |
10 °C (50 °F) | ~ 60 minutes | ~3 hours |
15 °C (59 °F) | ~ 50 minutes | ~3 hours |
20 °C (68 °F) | ~ 45 minutes | ~2 hours |
25 °C (77 °F) | ~ 35 minutes | ~2 hours |
30 °C (86 °F) | ~ 30 minutes | ~2 hours |
Times are approximate and will be affected by changing ambient conditions particularly temperature and relative humidity.
Consumption
As Neat Base Coat Membrane: ~ 0.5 - 0.6 m2/L (20 - 25 ft2/ US gal.) at 64 - 80 mil (d.f.t / w.f.t) depending on the system applied.
As Wear Course Layer (Resin filled at 1:2 ratio, by weight with Sikalastic®-1 Pronto Filler): ~ 0.5 - 1.3 m2/L (19 - 54 ft2/ US gal.) at 30 - 83 mil d.f.t/w.f.t.) depending on the system applied.
These figures are theoretical and do not allow for any additional material due to surface porosity, surface profile, variations in level or wastage, etc. For detailed info, refer to the System data sheet Sikalastic® Pronto RB-5700 PUMA.
MIXING
Mixing Tools
For indoor work, spark-free mixing equipment must be used (explosion-proof)! Sikalastic®-532 Pronto must be thoroughly mixed using a low speed electric stirrer (300 - 400 rpm) or other suitable equipment. Use Jiffy-type mixer to ensure adequate dispersion when blending Sika Extender T into Sikalastic-532 Pronto for inclinations and vertical applications.
Over mixing must be avoided to minimize air entrainment. For ease of handling, 18.9 L (5 US gal.) units may be split (2 x 9.5 L / 2.5 US gal.) (refer to Mixing table). Always measure out components.
Neat Base Coat Layer
Mix Sikalastic®-532 Pronto thoroughly, for at least one (1) minute, then add the hardener in the correct quantity and mix for one (1) additional minute.
Broadcast Wear Course:
Mix Sikalastic®-532 Pronto thoroughly 1:2 ratio, by weight with Sikalastic®-1 Pronto Filler for at least one (1) minute, then add the hardener in the correct quantity and mix for one (1) additional minute. Hardener dosage is based on Sikalastic®-532 Pronto quantity prior to addition of Sikalastic®-1 Pronto Filler.
For estimating purposes: ~ 1 L of slurry mixture will require ~ 0.6 L (0.6 kg) Sikalastic®-532 Pronto mixed with ~ 1.2 kg Sikalastic®-1 Pronto Filler.
APPLICATION
Prior to application, confirm substrate moisture content, relative air humidity and dew point. For exterior applications, apply when temperatures are falling. If applied during rising temperatures “pin holing” may occur from rising air.
Levelling
Rough surfaces need to be levelled first. Therefore use e.g. Sikalastic®-511 Pronto Primer at 1:2 ratio, by weight with Sikalastic®-1 Pronto Filler as a leveling mortar (see System Data Sheet). Apply by squeegee / trowel to the required thickness.
Neat Base Coat Layer
Sikalastic®-532 Pronto is poured, spread evenly by means of a serrated trowel or V-notched squeegee. Roll immediately in one direction with a spiked roller to ensure even thickness and to remove entrapped air.
Broadcast Wear Course
Sikalastic®-532 Pronto mixed at 1:2 ratio, by weight with Sikalastic®-1 Pronto Filler is poured, spread evenly by means of a serrated trowel or V-notched squeegee. Roll immediately in one direction with a spiked roller to ensure even thickness and to remove entrapped air. Immediately afterwards, broadcast with quartz sand.
Note: Broadcast quartz sand in three (3) steps, begin with light application, building up to excess in order to ensure an even distribution of quartz sand and to avoid misplacing of the material. The material cures very quickly and therefore application must be carried out steadily and “wet on wet” in order to achieve joint-free floors.
CLEAN UP
Clean all tools and application equipment with Urethane Cleaner and Thinner immediately after use. Hardened and/or cured material can only be removed mechanically.
